Promag MF700-10 sector reader of MIFARE® chips
(Product ID: 1117)

Documents:

Promag MF700

Promaf MF700-10 is wall-mounted reader which can be configured to read the data from the memory of MIFARE® chips.

It supports MAD1 or MAD2 standard and customer defined MAD-AID settings.

It also supports Non-MAD format with user-defined sector numbers and multi Sectors. You can install it on metal surface and it is weather resistant.

If you need larger quantities send an email to info@rfidspecialist.eu or call +386 41 884 124 and we will be happy to help you.

If you are an integrator or reseller, we offer special discounts.

Article order inquiry

Send us your inquiry and we will answer you as soon as possible.

You message has been sent!

< Backward

Name and Surname:

Company:

Vat number:

Country:

E-mail:

Phone:

Articles, quantity, deadline:

Send inquiry

INFO

The MF700 reader is designed for situations where it is necessary to read the data recorded on the card.
Examples are: access control systems, guest registration systems, identification, time attendance, etc.

The MF700 operates between 7,5 V and 24 V and reads MIFARE Classic® 1K / 4K.

Reader	Promag MF700
Model:	MF700-10
Housing	ABS material
Frequency:	13,56 MHz
Suitable for chips:	MIFARE Classic® 1k ali 4k
Interface:	Wiegand 26 bits ~ 128bits Selectable, RS232, MSR ABA TK2
Reading distance:	0-5 cm
Dimensions:	47 x 83 x 16 mm
Environment:	Operating temperature: 0 °C ~ +60 °C Operating humidity: 10~90%
Power requirements	7,5 - 24 V DC
Possible to be installed on metal surface	YES

If you need larger quantities send an email to info@rfidspecialist.eu or call +386 41 884 124 and we will be happy to help you.

If you are an integrator or reseller, we offer special discounts.

MIFARE® and MIFARE CLASSIC® are registered trademarks, owned by NXP B.V. There is no affiliation between NXP B.V. and RFIDspecialist (Mave d.o.o.).
