SDC-86EK EM Built-in Access Control with PIN Code and RFID 125 kHz
(Product ID: 3797)

The SDC-86EK EM is a built-in standalone device designed for door opening via PIN code and RFID chips operating at a frequency of 125 kHz.

The device activates a voltage-free relay and can be used to open various electronic locks.

Key features of this device:

Housing dimensions: 86×86×20 mm, covering standard electrical boxes
Waterproof metal housing, IP68 rated
Capacity for up to 2,000 users
Door opening via RFID chip or PIN code
12V DC power supply
User management through administrative cards (Add User, Delete User)
Compatible with RFID chips type TK4100, EM4200, and encoded T5577 (125 kHz frequency)
Voltage-free relay for connecting electronic locks

For further information or an offer, contact us at info@rfidspecialist.eu. Our team of experts is here to assist and answer all your queries.

Special discounts available for integrators or resellers.

Price/item: 49,00 EUR (with vat 59,78 EUR)

Status: In stock

Dispatching time: 1-3 days

Product ID: 3797

Quantity:

Total:

49,00 EUR

Total with vat:

59,78 EUR

Add to cart

Do you need print or other specific requirements?

Send inquiry

INFO

The SDC-86EK EM is a high-quality device specifically designed for opening electromagnetic locks and suitable for built-in installation.

Upon successful authentication, the relay switch is activated, sending an impulse to the electronic lock, opening the door and enabling access to the facility.

Technical Specifications:

Model: SDC-86EK EM
Dimensions: 86×86×20 mm
Power Supply: 12V DC
Access Method: RFID chip or PIN code
Frequency: 125 kHz
Supported Chips: TK4100, EM4200, and encoded T5577
Housing: Metal
Maximum Users: 2,000 users
Relay Impulse Duration: 0-99 seconds
Maximum Relay Load: 3A
Indicators: LED, buzzer
Operating Temperature: -40°C to 60°C
Humidity: 0% to 95% (IP68 waterproof housing)
Reader Range: 2-5 cm
