Promag MF7 wall RFID reader for MIFARE® chips
(Product ID: 1116)

Documents:

Promag MF7

Promag MF7-20 is wall-mounted proximity reader which reads the UID from 13,56 MHz chips MIFARE® Classic, Ultralight and DESFire.

You can install it on metal surface and it is weather resistant.

It supports 3 communication protocols: Wiegand 26 bits, MSR ABA TK2 and RS232.

Usually it is used with access control devices or for other identification purposes.

If you need larger quantities send an email to info@rfidspecialist.eu or call +38641 884 124 and we will be happy to help you.

If you are an integrator or reseller, we offer special discounts.

Price/item: 75,00 EUR (with vat 91,50 EUR)

Status: In stock

Dispatching time: 1-3 days

Product ID: 1116

Quantity:

Total:

75,00 EUR

Total with vat:

91,50 EUR

Add to cart

Do you need print or other specific requirements?

Send inquiry

INFO

The MF7 is compatible with ISO14443A standard series and operates between 5V and 18V. Under optimal conditions, the reading distance is up to 50 mm. It also contains an LED and buzzer speaker which can be freely programmed.

Reader:	Promag MF7
Model:	MF7-20
Housing:	ABS material
Frequency:	13,56 MHz
Suitable for chips:	MIFARE Classic®, Ultralight, DESFire® (UID)
Interface:	Wiegand 26 bits, RS232, MSR ABA TK2
Reading distance:	0-5 cm
Dimensions:	47 x 83 x 16 mm
Environment:	Operating temperature: -10 °C ~ +60 °C Operating humidity: 10~90%
Power requirements	5 - 18 V DC
Possible to be installed on metal surface	YES

Technical documentation and software tools:
http://ftp.gigatms.com.tw/doc/MF7/

If you need larger quantities send an email to info@rfidspecialist.eu or call +38641 884 124 and we will be happy to help you.

If you are an integrator or reseller, we offer special discounts.

MIFARE® and MIFARE CLASSIC® are registered trademarks, owned by NXP B.V. There is no affiliation between NXP B.V. and RFIDspecialist (Mave d.o.o.).
